Specifications
- Detection Technology
- Sensor Type: Semiconductor or catalytic sensors for high sensitivity and accuracy.
- Gas Detection Range: 0-100% Lower Explosive Limit (LEL).
- Response Time: <10 seconds for quick leak detection.
- Detection Capability
- Specifically designed for LPG gases (propane and butane).
- Additional capability to detect methane or other hydrocarbons (optional models).
- Operating Voltage
- AC Models: Operates on 220V/110V AC power supply.
- DC Models: Operates on 12V/24V DC, ideal for vehicles and off-grid locations.
- Alarm System
- Audible Alarm: Loud alarm with ≥85 dB sound at 1 meter.
- Visual Alarm: LED indicator for status and leak alerts (e.g., red for leak, green for normal).
- Output Options: Relay outputs for integration with external alarms or automatic shut-off systems.
- Power Consumption
- Low power consumption: Typically ≤3W for energy efficiency.
- Housing and Build
- Material: High-quality ABS plastic or flame-retardant polycarbonate.
- Compact and lightweight design for easy wall or ceiling mounting.
- Operating Conditions
- Temperature Range: -10°C to +55°C (14°F to 131°F).
- Humidity Range: <95% RH (non-condensing).
- Designed to function in various environments, including kitchens, industrial plants, and confined spaces.
- Calibration
- Factory pre-calibrated for immediate use.
- Field calibration supported for long-term reliability.
- Connectivity and Integration
- Compatible with home automation systems, fire alarm panels, and shut-off valves.
- Wireless or wired models available based on requirements.
- Certification and Standards
- Certified to meet international safety standards like EN 50194, UL 1484, and local fire codes.
- Applications
- Residential Spaces: Kitchens, LPG storage areas, and enclosed spaces.
- Commercial Properties: Restaurants, hotels, and LPG filling stations.
- Industrial Facilities: Factories, warehouses, and gas processing plants.
- Vehicles: LPG-powered cars, trucks, and RVs.
